Document generation is usually quick when a single document is requested by one user. However, problems arise when an application must simultaneously create thousands of invoices, statements, contracts, reports, or policy documents. A few hundred milliseconds per document adds up at that point, creating a queue that becomes a production bottleneck.

Create 100,000 documents in under an hour. According to the benchmark results below, the fastest measured setup processed 50 documents in 1,625 milliseconds with 7 workers. Extrapolating to 100,000 documents, this would take approximately 54 minutes on the measured system and document set.

The TXTextControl.DocumentServer.ParallelMailMerge NuGet package provides a simple ParallelMailMerge component for .NET applications. It is designed for scenarios where you want to accelerate TX Text Control MailMerge jobs by sending parallel requests to isolated worker processes.

Use parallel MailMerge when document generation is repeated many times, such as invoice runs, batch reports, customer portals, document queues, or background services. The calling code stays close to the regular MailMerge workflow, but the work can be distributed across multiple workers.

When to Use Parallel MailMerge

Parallel processing is useful when the problem is generating documents quickly. While a single document request may be fast, high-volume workloads benefit from processing several independent merge jobs simultaneously.

Typical use cases include:

• Generating large invoice batches at the end of a billing period.
• Creating personalized contracts, letters, statements, or certificates.
• Serving many concurrent document requests from a customer portal.
• Running background queues that convert templates and JSON data into PDF or DOCX output.
• Scaling document generation without redesigning the application around a separate Web API.

Installing the Package

The package is available on NuGet:

dotnet add package TXTextControl.DocumentServer.ParallelMailMerge --version 34.0.0

The consuming project also references TX Text Control so the worker process can load the document engine and use the application's TX Text Control setup.

Startup Code

Add the worker handoff at the beginning of the application entry point. When the process is started as a worker, this method runs the worker loop and returns true. In the normal application process, it returns false and the application continues.

using TXTextControl.DocumentServer.Parallel;

if (await ParallelMailMerge.TryRunWorkerAsync(args))
{
    return;
}

Merging One Template

The API is intentionally close to the regular MailMerge component. Create one ParallelMailMerge instance, configure the number of workers, load the template and JSON data, and write the result.

using TXTextControl;
using TXTextControl.DocumentServer;
using TXTextControl.DocumentServer.Parallel;

await using var mailMerge = new ParallelMailMerge(new TXWorkerOptions
{
    WorkerCount = 5
});

var result = await mailMerge.MergeJsonDataAsync(
    await File.ReadAllBytesAsync("invoice.docx"),
    FileFormat.WordprocessingML,
    await File.ReadAllTextAsync("invoice.json"),
    BinaryStreamType.AdobePDF,
    settings: new MailMergeSettings
    {
        UseTemplateFormat = true,
        RemoveEmptyFields = true,
        RemoveEmptyBlocks = true
    });

await File.WriteAllBytesAsync("invoice.pdf", result.Document);

Using ParallelMailMerge in an ASP.NET Core Web API

In an ASP.NET Core Web API, register one ParallelMailMerge instance as a singleton and reuse it for all requests. This keeps the worker pool alive instead of starting new workers for every HTTP request.

The worker handoff must still be the first application code in Program.cs. After that, configure the Web API normally:

using TXTextControl;
using TXTextControl.DocumentServer;
using TXTextControl.DocumentServer.Parallel;

if (await ParallelMailMerge.TryRunWorkerAsync(args))
{
    return;
}

var builder = WebApplication.CreateBuilder(args);

builder.Services.AddSingleton(_ => new ParallelMailMerge(new TXWorkerOptions
{
    WorkerCount = 7,
    RequestTimeoutSeconds = 120
}));

var app = builder.Build();

app.MapPost("/api/mailmerge/pdf", async (
    MergeRequest request,
    ParallelMailMerge mailMerge,
    CancellationToken cancellationToken) =>
{
    var result = await mailMerge.MergeJsonDataAsync(
        Convert.FromBase64String(request.TemplateBase64),
        FileFormat.WordprocessingML,
        request.MergeJson,
        BinaryStreamType.AdobePDF,
        settings: new MailMergeSettings
        {
            UseTemplateFormat = true,
            RemoveEmptyFields = true,
            RemoveEmptyBlocks = true
        },
        cancellationToken: cancellationToken);

    return Results.File(result.Document, "application/pdf", "merged.pdf");
});

await app.RunAsync();

public sealed record MergeRequest(string TemplateBase64, string MergeJson);

The client sends the DOCX template as Base64 and the merge data as JSON. The Web API returns the generated PDF directly from the worker result. For production applications, the template can also come from storage, a database, or a predefined server-side template repository instead of being uploaded with every request.

Merging Multiple Files

The performance benefit appears when multiple independent merge jobs are sent to the same ParallelMailMerge instance. The worker pool distributes the requests across the configured workers.

var jobs = new[]
{
    new { Template = "invoice-1001.docx", Data = "invoice-1001.json", Output = "invoice-1001.pdf" },
    new { Template = "invoice-1002.docx", Data = "invoice-1002.json", Output = "invoice-1002.pdf" },
    new { Template = "invoice-1003.docx", Data = "invoice-1003.json", Output = "invoice-1003.pdf" }
};

await using var mailMerge = new ParallelMailMerge(new TXWorkerOptions
{
    WorkerCount = 5
});

await Task.WhenAll(jobs.Select(async job =>
{
    var result = await mailMerge.MergeJsonDataAsync(
        await File.ReadAllBytesAsync(job.Template),
        FileFormat.WordprocessingML,
        await File.ReadAllTextAsync(job.Data),
        BinaryStreamType.AdobePDF,
        settings: new MailMergeSettings
        {
            UseTemplateFormat = true
        });

    await File.WriteAllBytesAsync(job.Output, result.Document);
}));

MailMerge Settings

The package exposes common MailMerge settings through MailMergeSettings. These options are applied inside the worker before the merge operation runs.

Benchmark Setup

The benchmark generated 50 documents for each worker count. The sample used a concurrency level of 50 and tested 1, 2, 5, and 7 workers.

{
  "SampleRunner": {
    "ResultsDirectory": "SampleApiTests/results",
    "DocumentCount": 50,
    "Concurrency": 50,
    "WorkerCounts": [1, 2, 5, 7],
    "TimeoutSeconds": 300,
    "DotNetHostPath": null
  }
}

The 7-worker run produced the fastest measured result, completing the 50-document batch in 1,625 milliseconds. Compared to the single-worker run, the total processing time decreased from 5,780 milliseconds to 1,625 milliseconds.

Interpreting the Results

The 5-worker and 7-worker runs both delivered strong throughput. The 7-worker run was the fastest in this measurement, while the 5-worker run already delivered most of the improvement with fewer processes. On multi-core, high-performance systems with more available CPU capacity, results can be even better because more workers can run efficiently in parallel.

More workers are not automatically faster. The average worker time increased from 103.3 milliseconds with one worker to 179.9 milliseconds with seven workers, which indicates additional coordination and resource contention. The right worker count is the point where total throughput improves without making each individual merge unnecessarily slower.

Conclusion

High-volume document generation is a perfect candidate for parallelization because each merge job is independent. The TXTextControl.DocumentServer.ParallelMailMerge package makes this pattern easy to adopt in console applications, Windows Forms applications, ASP.NET applications, background services, and other .NET project types.

If you want to accelerate document generation drastically, send parallel requests to ParallelMailMerge and tune the worker count for your workload. In the benchmark above, the best measured result projects to approximately 100,000 generated documents in 54 minutes, which is under an hour.

Frequently Asked Questions
