We are happy to announce the release of DS Server version 4.1.0, which offers a new way to enhance the capabilities of Text Control DS Server: A plug-in architecture that enables you to create and deploy external assemblies directly within your DS Server environment.

This new feature allows you to go beyond the built-in APIs and seamlessly integrate your own logic, routes, services, and middleware into the DS Server lifecycle.

Why Plug-ins?

Every application has unique requirements. Sometimes, you need to add a custom API endpoint, integrate external services, or perform custom startup and shutdown tasks. Until now, these use cases required external wrapping of the DS Server.

The new plug-in feature solves this by letting you:

• Register custom ASP.NET Core controllers to expose new API endpoints
• Add middleware to intercept requests for logging, metrics, or custom authentication
• Register services into DS Server's dependency injection container
• Hook into lifecycle events with startup and shutdown logic

This makes DS Server more than just a document backend; it's a fully extensible platform. In combination with TX Text Control .NET Server, you can offer the functionality of the TX Text Control API in the form of a DS Server plug-in. Additionally, you can offer plug-ins to other users, enabling them to incorporate your custom functionality into DS Server.

The IPlugin Interface

At the heart of this feature is the IPlugin interface, which defines how plug-ins integrate with DS Server:

namespace TXTextControl.DocumentServices.Plugin.Abstractions;

public interface IPlugin {
    string Name { get; }
    string Description { get; }
    string Version { get; }

    string UIBasePath => null; // Optional, for plugins with a web UI (e. g. /plugin-ui/config)

    void ConfigureServices(IServiceCollection services, PluginContext context) { }
    void ConfigureMiddleware(WebApplication app, PluginContext context) { }
    void OnStart(IServiceProvider services, PluginContext context) { }
    void OnStop() { }
}

This provides access to the DS Server configuration, base directory, and runtime environment via the PluginContext.

public class PluginContext {
    public string DsServerVersion { get; set; } = default!;
    public string BaseDirectory { get; set; } = default!;
    public IConfiguration Configuration { get; set; } = default!;
}

Hello, World! Plug-in

Let's create a simple "Hello, World!" plug-in that adds a new API endpoint to DS Server:

• A GreetingState service holds a configurable greeting.
• A controller exposes an endpoint at /plugin/hello.
• Middleware logs requests to this endpoint.
• The plug-in prints its greeting when DS Server starts.

1. Create a new class library project.

   dotnet new classlib -n MyFirstPlugin
   cd MyFirstPlugin

2. Add the abstraction package.

   dotnet add package TXTextControl.DocumentServices.Plugin.Abstractions

3. Define a service to hold config state.

   public class GreetingState {
       public string Greeting { get; set; } = "Hello (default)";
   }

   This service will be used to store and manage the greeting message.

4. Create a controller to handle requests.

   using Microsoft.AspNetCore.Mvc;

   namespace MyFirstPlugin;

   [ApiController]
   [Route("plugin/[controller]")]
   public class HelloController : ControllerBase {
       private readonly GreetingState m_state;

       public HelloController(GreetingState state) {
           m_state = state;
       }

       [HttpGet]
       public string Get() => m_state.Greeting;
   }

   This controller will respond to requests at /plugin/hello.

5. Implement the plug-in class.

   using Microsoft.Extensions.DependencyInjection;
   using Microsoft.Extensions.Logging;
   using TXTextControl.DocumentServices.Plugin.Abstractions;

   namespace MyFirstPlugin;

   public class HelloPlugin : IPlugin {
       public string Name => "MyFirstPlugin";
       public string Description => "Adds a /plugin/hello endpoint and logs requests.";
       public string Version => "1.0.0";

       public void ConfigureServices(IServiceCollection services, PluginContext context) {
           // Retrieve the greeting from the configuration and register it as a singleton service.
           // This is just an example. Implementing ConfigureServices is optional.
           var greeting = context.Configuration["MyFirstPlugin:Greeting"] ?? "Hello (default)";
           services.AddSingleton(new GreetingState { Greeting = greeting });
       }

       public void ConfigureMiddleware(WebApplication app, PluginContext context) {
           // Register a middleware to log requests to the /plugin/hello endpoint.
           // This is also just an example. Implementing ConfigureMiddleware is optional.
           app.Use(async (ctx, next) => {
               if (ctx.Request.Path.StartsWithSegments("/plugin/hello")) {
                   var logger = ctx.RequestServices.GetRequiredService<ILogger<HelloPlugin>>();
                   logger.LogInformation("MyFirstPlugin intercepted request to /plugin/hello");
               }
               await next();
           });
       }

       public void OnStart(IServiceProvider services, PluginContext context) {
           // This method is called when the plugin is started. You can use this to
           // initialize resources or perform startup logic. Implementing OnStart is optional.
           var logger = services.GetService<ILogger<HelloPlugin>>();
           var state = services.GetService<GreetingState>();
           logger?.LogInformation("Plugin started. Greeting: {Greeting}", state?.Greeting);
       }

       public void OnStop() {
           // Cleanup logic if needed. This is also optional.
       }
   }

   This class implements the IPlugin interface. It reads the greeting text from the configuration and registers a middleware to log requests.

After compiling, simply drop the DLL into the Plugins folder of your DS Server installation and restart the service. Then, your custom logic is live.

Configuration Support

Plug-ins can also support custom configuration sections in the DS Server appsettings.json file. This allows you to easily adjust settings without recompiling the plug-in.

For example, you can define a configuration section for the GreetingState service:

"MyFirstPlugin": {
  "Greeting": "Howdy from DS Server!"
}

Deployment in 3 Steps

Creating and deploying a DS Server plug-in is straightforward:

1. Implement the IPlugin interface in your class.
2. Compile the plug-in into a DLL.
3. Drop the DLL into the Plugins folder of your DS Server installation and restart the service.

The full sources of the sample plug-in can be found in our GitHub repository.

A More Powerful DS Server

The new plug-in system transforms DS Server into much more than just a REST API for document processing. It is now a customizable platform for your business needs, whether that means advanced logging, integration with external systems, or new APIs running alongside DS Server's built-in endpoints.

Get Started Today

Download DS Server 4.0 today and try it in your own environment. We have updated our documentation to include Linux-specific installation guides and deployment best practices for Docker and cloud platforms.

If you would like to test this on your own server, you can download a new on-premises trial version.

Trial Version

All licenses in the online store have been updated. Owners of a valid subscription can download the new installation package from the store.

Online Store

Updated Packages

When testing DS Server 4.1.0, please make sure to use the updated packages for .NET Core, Angular, and React.

NuGet (.NET Core)

The following NuGet packages have been released and are compatible with DS Server 4.0:

• TXTextControl.DocumentServices.DocumentEditor
  https://www.nuget.org/packages/TXTextControl.DocumentServices.DocumentEditor/4.1.0
• TXTextControl.DocumentServices.DocumentProcessing
  https://www.nuget.org/packages/TXTextControl.DocumentServices.DocumentProcessing/4.1.0
• TXTextControl.DocumentServices.DocumentViewer
  https://www.nuget.org/packages/TXTextControl.DocumentServices.DocumentViewer/4.1.0
• TXTextControl.DocumentServices.Admin
  https://www.nuget.org/packages/TXTextControl.DocumentServices.Admin/4.1.0

npm (Angular)

The following npm Angular packages have been released and are compatible with DS Server 4.0:

• @txtextcontrol/tx-ng-ds-document-editor
  https://www.npmjs.com/package/@txtextcontrol/tx-ng-ds-document-editor/v/4.1.0
• @txtextcontrol/tx-ng-ds-document-viewer
  https://www.npmjs.com/package/@txtextcontrol/tx-ng-ds-document-viewer/v/4.1.0
• @txtextcontrol/tx-ng-ds-document-processing
  https://www.npmjs.com/package/@txtextcontrol/tx-ng-ds-document-processing/v/4.1.0

npm (React)

The following npm React packages have been released and are compatible with DS Server 4.0:

• @txtextcontrol/tx-react-ds-document-editor
  https://www.npmjs.com/package/@txtextcontrol/tx-react-ds-document-editor/v/4.1.0
• @txtextcontrol/tx-react-ds-document-viewer
  https://www.npmjs.com/package/@txtextcontrol/tx-react-ds-document-viewer/v/4.1.0

See the change log for a complete list of changes.

We are excited to see what you will create with DS Server 4.1.0! As always, we value your feedback and are here to support you every step of your development journey.
